1A Series

產品介紹

产品类型：密封处理微型Toggle开关
规格参数
额定值：120VAC 5A/250VAC 2A
功率：Dependent upon contact material
机械寿命：30,000 make – and – break cycles.
接触电阻：10 mΩ max.initial @ 2-4VDC 100mA for both sliver and gold plated contacts.
绝缘电阻：1,000MΩMIN.
绝缘强度：1,000Vrms min@sea level.
工作温度范围：-30℃ to 85℃.

使用材质
外壳&铜头：Glass filled nylon 6/6, flame retardant,heat stabilized (UL94V-0).
摇杆：Brass,chrome plated with internal, O-ring seal atandard.
支撑支架： Brass or steel, tin plated.
支架固定片：Stainless Steel.
端子/弹片：copper alloy ,with silver or gold plated.
